Aluminium Hook-on ceiling tiles

Aluminium Hook-on ceiling tiles

Material: Aluminum plate >98%

Size: 600x600mm, 600x1200mm…

Thickness: 0.7 - 1.2mm

Perforated D1.8mm - D20mm with black woven tissue

Powder coating base on RAL standard color chart

Suspension frame and sync accessories

100% recycled aluminum

Certificate:

Certification/ Standard (ISO 9001-2015)

Certification/ Aluminum >98% (ASTM B209/B209M)

Certification/ Suspension frame system standard (ASTM C635)

Acoustic ratings: αw = 0,75 (ASTM C423-2017)

Light reflectance: LR = 0,60 (ASTM E1477-1998a)

Fire ratings: Class A (ASTM E84-2019)

Guarantee: 10 years

https://austronggroup.com.vn

Product description

Using a hidden suspension system, Austrong Hook - on square ceiling tiles gives the impression of a succinct cubic Hook - on ceilings tiles use a Z carrier to hold opposite edges of two panels to the main frame, ensuring that the panels are aligned and balance. With a large application in architecture and art for interior and exterior, a wide variety of square and rectangular ceilings, made from high standard aluminium alloy and a wide range of standard colours. With a non-woven textile membrane bonded to the inside face, Austrong Hook - on aluminum ceiling tiles is a highly effective soundproofing and soundproofing ceiling system.

Aluminum Hook - on Ceiling Tile Features:

The surface of Austrong Hook - on tile is perforated and equipped with a black non-woven fabric layer in back side for acoustic control and noise reduction. The product is easy to construct and install, does not require complicated tools and machinery. Compatible with industry standard lighting, audio speakers, fire safety, cameras, and security services etc. The product has high stability and is completely fireproof. and water resistant, not oxidized, completely eliminating the aggressive factor of the environment. Austrong Group has always researched and developed to create products

that are environmentally friendly, energy-conserving, efficient and sustainable. All Austrong Group products are 100% recyclable

Aluminum Hook - on Ceiling Tile Application:

Is perfect solution for Office Buildings, Schools, Hospitals, Commercial centers, Sports centers, Airport terminals, Banks, Hotels, Telecommunications centers, Television centers ....

Product structure

Color and coating

Austrong Vietnam offers a wide range of colors and finishes surface. Colors are available according to the color chart below, can be made base on requirements.

Please contact Austrong Vietnam sales department.

Colours are for illustration purposes only
