Product Structure: 132S Sun Louver
Color: 132S Sun Louver
Austrong Vietnam offers a wide range of colors and surface finishes. Standard colors are available in the palette below; other custom colors and finishes can be produced upon request. Please contact Austrong Vietnam’s Sales Department for more information.
Note: For additional color options, please refer to the Ral Color K5 Classic chart.
Product Information: 132S Sun Louver
| Product Name | 132S Sun Louver |
| Dimensions | 132 (mm) |
| Material Thickness | 0.6 – 0.8 (mm) |
| Main Material | Aluminum A3003 H14-H24 |
| Surface Coating | PE / PVDF Coating |
| Supporting Frame System | Aluminum, Galvanized Steel |
Quality Standards: 132S Sun Louver
| Quality Management System | ISO 9001-2015 |
| Material Standard | ASTM B209/B209M-21a |
| Fire Resistance Standard | QCVN 06:2022/BXD |
| Surface Coating Standard | ASTM D3359-93 |
Đặc điểm nổi bật: 132S Sun Louver
-
- Manufactured from Aluminum Alloy 3003 H14–H24, 0.6 – 0.8 mm thick, ensuring excellent strength and durability.
- Designed with Z-shaped aluminum blades, 132 mm wide and inclined at 45°, optimizing sun shading and airflow.
- Integrated mounting system for easy installation and perfect alignment.
- High-quality PE/PVDF coating, UV-resistant, and suitable for Vietnam’s tropical climate.
- Customizable lengths based on project requirements — no dimensional limitation.
- Fire-resistant, waterproof, and non-oxidizing, ensuring long-term outdoor durability.
- 100% recyclable, environmentally friendly, and contributes to energy-efficient green buildings.
Applications: 132S Sun Louver
The Austrong 132S Sun Louver system is ideal for projects requiring aesthetic appeal, effective sun protection, and long-term performance, such as: Office Towers, Schools, Hospitals, Administrative Centers, Shopping Malls, Supermarkets, Showrooms, Airports, Train Stations, Bus Terminals, Banks, Hotels, Resorts, Convention Centers, Broadcasting & Telecommunication Buildings, and other Public Facilities.
